AGM AUTROY AUTHP-3000CP

Automatic Pocket Hemming Machine

TECHNICAL SPECIFICATIONS

Automatic pocket hemming machine for jeans and similar, three needles, chain stitch, adjustable folder.
AGM AUTROY touch screen control panel for easy setting of the machine functions.
Three needle chain stitch sewing head with servo direct drive motor.
The machine allows to perform the hemming on different fabric types (from the denim to the stretch) through simple settings and without replacing any device.
Photo sensors for fabric detecting.
Automatic thread trimmer and vacuum system for thread waste.
Rotating stacker for proper pockets stacking and collection.
Air compressor works when the chain cutter is activated.
Sensors for thread breaking detecting.
Between 5mm and 25 mm a single adjustable folder allows to realize single and double hem and change the height of the hemming.

Control panel to adjust chains at beginning and end of the pocket.
Easy maintenance and setup of the device.
The machine is also equipped with a sewing head pull back system
and a conveyor belt lifting up system, to make the threading and the most common maintenance operations easy.
Electronic control unit developed by AGM AUTROY Software updates
via USB memory.
Intermittent conveyor belt synchronized with the feed dog and powered by electronic motor.
Thread breakage sensor.
Automatic thread trimmer.
One leg adjustable stand.
Pneumatic transport system
